首頁 >> 服務器 >> 4U 8卡/10卡 GPU服務器 >> ZXZY-ESC8000-G8

ZXZY-ESC8000-G8

☆搭載第2代英特爾Xeon可擴展平臺
☆高密度 GPU 服務器搭載混合運算能力
☆ASUS 可調式拓?fù)鋵＠O(shè)計
☆可擴展設計適合日益成長的工作負載
☆全方位 IT 基礎架構管理解決方案
☆熱插入冗余風扇和專用空氣通道提供有效散熱
☆專屬 Thermal Radar 技術提高能源效率
☆簡化維護與管理
- 價格：￥0.00

  市場價：￥0.00

商品信息

商品描述

☆搭載第2代英特爾Xeon可擴展平臺

☆高密度 GPU 服務器搭載混合運算能力

☆ASUS 可調式拓?fù)鋵＠O(shè)計

☆可擴展設計適合日益成長的工作負載

☆全方位 IT 基礎架構管理解決方案

☆熱插入冗余風扇和專用空氣通道提供有效散熱

☆專屬 Thermal Radar 技術提高能源效率

☆簡化維護與管理

處理器 / 系統總線
2 x Socket P (LGA 3647)
1st and 2nd Gen Xeon? Scalable Processor Family
*Refer to support page for more information
內存
Total Slots : 24 (6-channel per CPU, 12 DIMM per CPU)
Capacity : Maximum up to 3072GB RDIMM
Memory Type :
DDR4 2933/2666/2400 /2133 RDIMM
DDR4 2933/2666/2400 /2133 LRDIMM
DDR4 2933/2666/2400 /2133 LR-DIMM 3DS
DDR4 Intel? Optane? DC Persistent Memory
Memory Size :
64GB, 32GB, 16GB RDIMM
128GB, 64GB, 32GB LRDIMM
128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information
擴展槽
Full-length/Full-height:
8 x PCI-E x16 (Gen3 x16 link), FH, FL
* Single root topology : 8 from CPU1
Dual root topology : 4 from CPU1, 4 from CPU2
Half-length/Low-profile:
Rear:
Dual root topology: 2 x PCI-E x16 (Gen3 x 16 link),LP,HL
(1 from CPU1,1 from CPU2)
or
Single root topology: 1 X PCI-E x16 (Gen3 x16 link),LP,HL
(from CPU1)
Front:
1 x PCI-E x8 (Gen3 x8 link),LP,HL (from CPU2)
存儲功能（視出貨而定）
SATA Controller :
Intel? C621
8 x SATA3 6Gb/s ports + 2 x M.2 connector (SATA 6Gb/s & PCIe? Gen3 x4 link 22110/2280/2260)
or
6 x SATA3 6Gb/s ports + 2 x NVMe drives + 2 x M.2 connector (SATA 6Gb/s & PCIe? Gen3 x4 link 22110/2280/2260)
Intel? Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows)
(Support Software RAID 0, 1, 5, 10 )
Intel?VROC (For Linux/Windows)
(Support Software RAID 0/1 )
Optional kits Controller :
ASUS PIKE II 3008 8-port SAS HBA card
ASUS PIKE II 3108 8-port SAS HW RAID card
12G SAS Support
網絡(視出貨而定)
1 x Dual Port Intel I350-AM2 Gigabit LAN controller + 1 x Mgmt LAN
支持多顯卡
Please find the latest GPU support
前置 I/O 接口
2 x USB 3.0 ports
2 x USB 2.0 ports
1 x VGA port
1 x COM port
后置 I/O 接口
2 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port
開關/LED
Front Switch/LED:
1 x Q-Code/Port 80 LED
1 x Power switch/LED
1 x Location switch/LED
1 x HDD Access LED
1 x Message LED
Front Switch/LED:
1 x Q-Code/Port 80 LED
1 x Power switch/LED
1 x Location switch/LED
1 x HDD Access LED
1 x Message LED
2 x LAN LED
管理功能
Control Center Enterprise (Optional)
On-Board ASMB9-iKVM for KVM-over-IP
合規性認證
BSMI, CE, FCC(Class A)
外形尺寸
798mm x 439mm x 175.6mm (4U)
31.42" x 17.22" x 6.92"
尺寸規格
4U
電源
2+1 Redundant 1600W 80PLUS Platinum Power Supply;
100-127 / 200-240Vac, 12.9 / 9.5A（for each
inlet）, 47-63Hz, Class I
2+1 Redundant 2200W 80PLUS Platinum Power Supply
Rating: 100-127/200-240 Vac, 12.9/9.5 A (for each inlet), 47-63 Hz, Class I
*2200W Power supply is only available for selected countries.
環境
Operation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
